Description

Telescopic slides Schock Metal over extension series 036

Article price and sale per piece

Article No. Schock 036.19786 – 036.19790 as well as 036.11650 – 036.11653

Telescopic slides series 036, hot-dip galvanized steel, width 14.5 mm , over-extension, insertion pins, self-closing, up to 70 kg /pair at 10.000 cycles, 50 kg /pair at 100.000 cycles

Description telescopic slide SM-036C

• Full extension with over extension
• Load capacity up to 70 kg per pair
• Self-closing 25 mm
• Insertion pins

Material:

• Rails made of hot-dip galvanized steel
• Ball cages made of galvanized steel
• Balls made of hardened carbon steel

Temperature range:

• Operating temperature 10 C to 40 C (50 F to 104 F)
• Storage and transport temperature -20 C to max. 80 C (-4 F to 140 F)

Notes: The 25 mm long self-closing device automatically pulls the drawer slides into the closed end position. The insertion pins allow quick and tool-free assembly and disassembly of the drawer, for example for cleaning purposes. The specified load capacities are maximum values for a vertically mounted pair of telescopic slides with even load distribution when using all the intended mounting positions.
